Plent Machinery’s Manual Operated ABB series Fog Fire Monitor or Jet Fire Monitor provide variable and adjustable fog spray service. With Anti-corrosive aluminum alloy main body, this fire monitor is capable to work in the pressure 7-16bar condition. And the max testing pressure will be 26bar.
Plent Machinery’s Manual Operated ABB series Fog Fire Monitor or Jet Fire Monitor provide variable and adjustable fog spray service. With Anti-corrosive aluminum alloy main body, this fire monitor is capable to work in the pressure 7-16bar condition. And the max testing pressure will be 26bar.
Plent Manual Fire Fighting Fixed Station Fog Fire Monitor or Jet Fire Monitor ABB series is featured with Dual Handwheel to operate the model. Like other models, it also has various color finish for customer’s choice, including red, blue, yellow, grey. For More Info., please kindly refer to below tech data sheet.
|
Product |
ABB- Series Manual Operated Fog Fire Monitor or Jet Fire Monitor |
||
|
Model# |
PS10/20W-ABB |
PS10/30W-ABB |
PS10/40W-ABB |
|
Working Pressure |
10Bar / 145PSI |
10Bar / 145PSI |
10Bar / 145PSI |
|
Flow Rate |
1200lpm (317GPM) |
1800lpm (475GPM) |
2400lpm (635GPM) |
|
Max Reach |
≥50m |
≥60m |
≥65m |
|
Travel Range |
0°~360° (Horizontally)/ -55°~+70°(vertically, customized service available) |
||
|
Waterway Size |
3”(76.2mm) |
||
|
Jetting Pattern |
Jet or Fog Spray |
||
|
Max Fog Angle |
120° |
||
|
Product Material |
Aluminum Alloy (Monitor Body and Nozzle), Stainless Stee● (Tiller Bar) |
||
|
Monitor Inlet |
4”Flange or Bigger size( available for customized design) |
||
|
Monitor Outlet |
2.5”(63.5 mm) |
||
|
Weight (N.W.) |
14.8 kg (32.56 lbs) |
||
|
Country of Origin |
Made in China |
||
|
Trademark |
Shengxin Firepro Tech or Customized |
||
1. Durable and Light Alloy Construction
2. Efficient cast-in turning vane design
3. Compact and easy to operate
4. Experienced R&D Team for design and aftersales service
5. Ideal for marine, offshore, industrial and other corrosive environment
6. Competitive cost
7. 1-Year Warranty
● Oil & Gas
● Fuel Storage Area
● Fire & Rescue
● Mining
● Sea Conditions
● Chemical Industry
For More info about Ningbo Plent ABB- Series Manual Operated Fog Fire Monitor or Jet Fire Monitor, feel free to contact us any time.
