Plent Portable Jet/Fog Fire Monitor’s production is under ISO 9001 quality control management system. Each unit of Portable Jet/Fog Fire Monitor from Plent Machinery will be tested before shipment. And we will offer 1-Year Warranty.
Portable Jet/Fog Fire Monitor has single inlet in 2.5” with various options of connection type. For more info., please kindly refer to below tech data sheet.
|
Product Name |
Plent Portable Jet/Fog Fire Monitor |
||
|
Model# |
PSY6/20W-B |
PSY6/30W-B |
PSY8/40W-B |
|
Working Pressure |
6 Bar / 87 PSI |
6 Bar / 87 PSI |
8 Bar / 116 PSI |
|
Flow Rate |
1200 LPM (317 GPM) |
1800 LPM (475 GPM) |
2400 LPM (634 GPM) |
|
Max Reach |
≥50m |
≥63m |
≥71m |
|
Travel Range (Horizontally) |
-20°~+20° |
||
|
Travel Range (Vertically) |
+20°~+70° (Personnel Operating) / +30°~+70° (without Personnel Operating) |
||
|
Max Fog Angle |
120° |
||
|
Jetting Pattern |
Jet or Fog |
||
|
Monitor Inlet |
2.5” (available for customized design) |
||
|
Monitor Outlet |
2.5” (63.5 mm) |
||
|
Product Weight (N.W.) |
10 kg |
||
|
Product Material |
Aluminum Alloy (Monitor Body and Nozzle) |
||
|
Connection Type |
Ghost, Storz, Instantaneous, NH etc |
||
|
Trademark |
SXFIRE or Customized |
||
1. Durable and Light Alloy Construction
2. Efficient cast-in turning vane design
3. Compact and easy to operate
4. Experienced R&D Team for design and aftersales service
5. Ideal for Fire Truck, Fireman application
6. Multifunction nozzle with adjustable Flow
7. 1-Year Warranty
● Oil & Gas
● Fuel Storage Area
● Fire & Rescue
● Mining
● Sea Conditions
● Chemical Industry
For More info about Plent Portable Jet/Fog Fire Monitor products, feel free to contact us any time.
